Swing Arm

Project 2.1

Onshape Skill Development

Sketch Tools: Front Sketch Plane, Center Point Circle, Construction Line, Dimension Tool, Line Tool, Tangent Constraint,

Feature Tools: Fillet Tool, Extrude Tool, Rollback Bar, Display Mass Properties

Snap Gauge

Project 2.2

Start Now

Onshape Skill Development

Sketching Tools: Corner Rectangle, Center Point Arc, Center Point Circle, Corner Rectangle (Slot), Midpoint Constraint

Feature Tools: Extrude (New), Extrude (Remove), Chamfer, Fillet, Assign Material, Mass Properties Check

Bearing

Project 2.3

Start Now

Onshape Skill Development

Sketching Tools: Center Point Circle, Equal Constraint, Dimension Tool, Line Tool, Tangent Constraint, Trim Tool, Slot Tool, Construction Line

Feature Tools: Extrude (New), Extrude (Add), Assign Material, Mass Properties Check

Project Set 2

Basic Sketching and Part Modeling

This set of projects is ideal for beginners looking to continue learning feature-based modeling using Onshape. They offer a clear, step-by-step workflow to guide you through creating your first part models. Each tutorial focuses on circular geometry, internal features, and revision-friendly design strategies that build confidence in parametric modeling.
